Corrugated container houses are retrofitted from shipping containers, featuring an all-steel structure with seamless welding. They offer multiple protective functions, including corrosion resistance, waterproofing, windproofing, fireproofing, and seismic resistance. Built with a robust frame and steel plates, they have a lifespan of over 10 years and can be recycled and reused, making them more durable and eco-friendly than traditional prefabricated houses.
They have a wide range of applications, commonly serving as worker dormitories on construction sites, and can also meet needs for temporary offices and warehousing. Their advantages lie in their durability, which reduces long-term costs, and their multiple protective features that ensure safety. Their reusability aligns with green concepts, and their rapid assembly perfectly meets the immediate demands of temporary spaces.
| Category | External Dimensions | Specification |
| Basic Characteristics | External Dimension | 6000mm (L) × 3000mm (W) × 2890mm (H) |
| Internal Dimensions | 5850mm (L) × 2850mm (W) × 2520mm (H) | |
| Net Weight | Approx. 1100 KG | |
| Frame Structure | Column | 2.75 Special-Shaped Steel |
| Bottom Beam | 2.0 Special-Shaped Steel | |
| Top Beam | 2.0 Special-Shaped Steel | |
| Bottom Beam Square Tube Crossmember | 1.5 Q235 Galvanized Steel Pipe | |
| Top Beam Square Tube Crossmember | 1.7 & 1.2 Q235 Galvanized Steel Pipe | |
| Wall Panels | All Exterior/End Panels | 50mm Rock Wool Sandwich Panel (0.286) |
| Roof | Corrugated Sheet | 980# Corrugated Tile (0.526) |
| nsulation Layer | 30mm Glass Wool Blanket | |
| Ceiling | Ceiling Panel | 831# Corrugated Sheet (0.256) |
| Floor | Floor Panel | 18mm Cement Fiber Board |
| Door | Door | Steel Door; Inner Frame Size: 980mm × 2030mm |
| Window | Window | UPVC Sliding Window (White, Single-Slide), 1100mm × 930mm |
| The images and specifications shown are for reference only. The final effect and implementation plan are subject to the actual execution. | ||
