The Corrugated Box is an eco-friendly packaging container made from PP (polypropylene) or corrugated fiberboard, renowned for its unique wavy structural design. This structure not only provides excellent compression resistance and cushioning but also makes the box lightweight, waterproof, and fully recyclable. Available in various colors and customizable sizes, it is an ideal packaging solution that balances functionality with aesthetics.
Corrugated container houses are retrofitted from shipping containers, featuring an all-steel structure with seamless welding. They offer multiple protective functions, including corrosion resistance, waterproofing, windproofing, fireproofing, and seismic resistance. Built with a robust frame and steel plates, they have a lifespan of over 10 years and can be recycled and reused, making them more durable and eco-friendly than traditional prefabricated houses.
| Category | External Dimensions | Specification |
| Basic Characteristics | External Dimension | 6000mm (L) × 3000mm (W) × 2890mm (H) |
| Internal Dimensions | 5850mm (L) × 2850mm (W) × 2520mm (H) | |
| Net Weight | Approx. 1100 KG | |
| Frame Structure | Column | 2.75 Special-Shaped Steel |
| Bottom Beam | 2.0 Special-Shaped Steel | |
| Top Beam | 2.0 Special-Shaped Steel | |
| Bottom Beam Square Tube Crossmember | 1.5 Q235 Galvanized Steel Pipe | |
| Top Beam Square Tube Crossmember | 1.7 & 1.2 Q235 Galvanized Steel Pipe | |
| Wall Panels | All Exterior/End Panels | 50mm Rock Wool Sandwich Panel (0.286) |
| Roof | Corrugated Sheet | 980# Corrugated Tile (0.526) |
| nsulation Layer | 30mm Glass Wool Blanket | |
| Ceiling | Ceiling Panel | 831# Corrugated Sheet (0.256) |
| Floor | Floor Panel | 18mm Cement Fiber Board |
| Door | Door | Steel Door; Inner Frame Size: 980mm × 2030mm |
| Window | Window | UPVC Sliding Window (White, Single-Slide), 1100mm × 930mm |
| The images and specifications shown are for reference only. The final effect and implementation plan are subject to the actual execution. | ||
